L3OUT EIGRP Ver 3.1(2m)

CONFIGURATION
- 2. L3OUT

CONFIGURATION

2. L3OUT 以外はL3OUT Staticと同じ
[NOTE] L3OUT Static Ver 3.1(2m)

2. L3OUT

Ver 3.1(2m)

Tenants > XXXXX > Networking > External Routed Networks
- Create Routed Outside
  - Name
  - VRF
  - External Routed Domain
  - Check the "EIGRP"
  - Autonomous System Number
  - Nodes and Interfaces Protocol Profiles
    - Name
    - Nodes
      - Node ID
      - Router ID
      - "Use Router ID as Loopback Address" is unchecked
    - EIGRP Interface Profiles
      - Name
      - EIGRP Policy(default)
      - Interface Type(Routed,SVI,Sub-IF)
        - Routed(Node,Path,IPv4 Primary Address)
        - SVI(Path Type,Node,Path,Encap,IPv4 Primary Address)
        - Sub-IF(Node,Path,Encap,IPv4 Primary Address)
  - External EPG Networks
    - Name
    - Subnet
      - IP Address
      - Scope(External Subnets for the External EPG)
