L2OUT Ver 3.1(2m)

CONFIGURATION
REFERENCE

CONFIGURATION

Ver 3.1(2m)

1. Access Policy

1) VLAN Pool
Fabric > Access Policies > Pools > VLAN
- Create VLAN Pool
  - Name
  - Allocation Mode
  - Encap Blocks

2) Domain
Fabric > Access Policies > Physical and External Domains
> External Bridged Domains
- Create Layer 2 Domain
  - Name
  - VLAN Pool

3) AEP
Fabric > Access Policies > Global Policies
> Attachable Access Entity Profiles
- Create Attachable Access Entity Profiles
  - Name
  - Domains

4) Interface Policy
Fabric > Access Policies > Interface Policies > Policies
- Create XXXXX

5) Interface Policy Group
Fabric > Access Policies > Interface Policies
> Policy Groups > Leaf Policy Groups
- Create Leaf Access Port Policy Group
  - Name
  - AEP and Each Interface Policies

6) Interface Profile
Fabric > Access Policies > Interface Policies > Profiles
> Leaf Profiles
- Create Leaf Interface Profile
  - Name
  - Interface Selectors
    - Name
    - Interface IDs
    - Interface Policy Group

7) Switch Profile
Fabric > Access Policies > Switch Policies > Profiles
> Leaf Profiles
- Create - Leaf Profile
  - Name
  - Leaf Selectors
    - Name
    - Blocks
  - Interface Selector Profiles

2. L2OUT

Tenants > XXXXX > Networking > External Bridged Networks
- Create Bridged Outside
  - Name
  - External Bridged Domain
  - Bridge Domain
  - Encap
  - Path Type
  - Node
  - Path
    ※Add
  - External EPG Networks
    - Name

3. Contract

Tenant > XXXXX > Networking > External Bridged Networks
> XXXXX > Networks > XXXXX > In the Work pane > Contract

REFERENCE

aci-howto
– 外部 L2 接続の設定
